1.Provide simple, safe, reliable operation.
2.Precision equipment and design programs that make the machines more durable.
3.Down time and waste reduction to ensure less cost-effectiveness.
4.High-qualily tension regulation.
5.Non-stop machine on precise color registration, the precision of overprint reach ±0.1mm.
6.Duct unique designs can be printed oily based-ink and water base-ink.
7.Higher strong washing fastness.
8.Can be very easily change difference size printing cylinder, and can be change the difference spec ink duct and anilox roller. Textile accessories, garment label, paper, all kinds of rolls paper and etc.
| Parameter | 6 Colours Model | 5 Colours Model | 4 Colours Model | 3 Colours Model | 1 Colour Model |
| Model No. | JR-1242 | JR-1241 | JR-1231 | JR-1222 | JR-1201 |
| Front Printing Colors | 4 colours | 4 colours | 3 colours | 2 colours | 1 colour |
| Back Printing Colors | 2 colours | 1 colour | 1 colour | 1 colour | 1 colour |
| Max Printing Length | 300mm | 300mm | 300mm | 300mm | 300mm |
| Min Printing Length | 111mm | 111mm | 111mm | 111mm | 111mm |
| Max Printing Width | 140mm | 140mm | 140mm | 140mm | 140mm |
| Max Printing Speed | 70m/min | 70m/min | 70m/min | 70m/min | 70m/min |
| Max Unwind & Rewind Roll Diameter | 350mm | 350mm | 350mm | 350mm | 350mm |
| Power Supply | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz | 220V 50/60Hz |
| Total Power | 6.7kw | 6.7kw | 6.7kw | 6.7kw | 3kw |
| Machine Weight | 950kg | 930kg | 820kg | 800kg | 240kg |
| Overall Dimension (L×W×H, mm) | 2300×780×1900 | 2300×780×1900 | 2300×780×1900 | 2300×780×1900 | 1825×540×1090 |
