| Main Technical Parameters | ||||
|---|---|---|---|---|
| Model | SJ-ABA600 | SJ-ABA800 | SJ-ABA1000 | SJ-ABA1200 |
| Suitable material | HDPE/LDPE/LLDPE/CACO3 | |||
| Film width(mm) | 100-600 | 200-800 | 400-1000 | 600-1200 |
| Film thickness(mm) | 0.01-0.15 | |||
| Max.output(kg/h) | 50 | 70 | 100 | 120 |
| Extruder | ||||
| Screw diameter | Φ45/Φ50 | Φ50/Φ55 | Φ55/Φ60 | Φ60/Φ65 |
| Screw L/D | 30:1 | |||
| Screw material | Sacm-645/38 crmoala | |||
| Cylinder material | Sacm-645/38 crmoala | |||
| Cylinder cooling | 250w*2 | 250w*2 | 250w*2 | 370w*2 |
| Main motor(kw) | 11/15 | 15/18.5 | 18.5/22 | 22/30 |
| Temperature control | 3 ZONE | 4 ZONE | ||
| Average power-consume(kw/h) | 25 | 35 | 40 | 55 |
| Die size(mm) | Φ60 | Φ80 | Φ120 | Φ160 |
| Temperature control | 1zone | 1zone | 2zone | 2zone |
| Air ring(mm) | 620 | 780 | 780 | 780 |
| Air blower(kw) | 2.2 | 3 | 3 | 4 |
| Traction unit | ||||
| Roller width(mm) | 700 | 900 | 1100 | 1300 |
| Traction speed(m/min) | 5-50 | 5-50 | 5-50 | 5-50 |
| Traction motor(kw) | 1.5 | 1.5 | 1.5 | 1.5 |
| Winding unit | ||||
| Type | Surface friction type | |||
| Winding motor(kw) | 1.5 | 1.5 | 1.5 | 1.5 |
| Winding speed(m/min) | 5-50m/min | |||
| Machine size(mm) | 4800*3000*6000 | 5200*2200*6200 | 5600*5800*6400 | 6000*3200*6700 |
| Machine weight(T) | 2T | 3T | 4T | 5T |
